Product Details:
|
Other Name: | Dewatering Equipment | Usage: | Dehydrate Kitchen/Organic Waste |
---|---|---|---|
Function: | Organic Waste Dehydration | Suitable Objects: | Vegetable And Fruit, Food Waste Etc. |
Material: | SUS304 | Motor: | Overload Protective |
Voltage: | 220V/380V, Can Be Customized | Feature: | Environmental, High Productivity, Low Energy Consumption |
Advantage: | High Efficiency, Low Cost, Can Be Customized | Service: | 1 Year Warranty, Provide Technical Support |
High Light: | SS304 Food Waste Shredder Machine,220V Food Waste Shredder Machine,High Productivity waste dehydration machine |
Shredding and Dewatering Equipment Two-in-one Machine for Food Waste Treatment
Product Description:
TOGO is promoting food waste dehydrators to businesses and institutions that generate large quantities of food waste, such as restaurants, hotels, grocery stores, universities, and prisons.
This food waste dewatering machine is suitable for the dehydration of food waste before or after fermentation.
Organic waste dehydrator can be widely used in the dehydration operation of high-humidity slag materials before drying, such as the dehydration of distiller’s grains, pomace, medicinal dregs, cassava dregs, etc., which greatly reduces the burden on the dryer, greatly increases the output, and consumes large The range is reduced, which is a piece of indispensable processing equipment for high-humidity materials before drying. The dehydrated materials can directly enter the drying equipment.
Model | Dewatering Machine |
Usage | Food Waste Dehydration |
Material | 304 Stainless Steel |
Voltage | 220V/380V |
Feature | Can be used in connection with composting machine |
Packaging | Standard export wooden case |
Warranty | 1 Year |
Service Life | 100000H |
Principle of use:
Pumping food waste into the pump of the extruded auger and sieving screen, and then performing spiral extrusion, there is a drain outlet to discharge the separated water, and the other port is the slag outlet. The water content of the material after dewatering is between 40% and 60%, and the wetness of the slag discharge and the pressing effect thereof may be different due to different materials. The slag outlet of the food waste dewatering machine can change the pressure effect on the material by adjusting the spring pressure or oil pressure, so as to adjust the drying degree of slag discharge. The squeezing effect will vary with different materials.
The food waste dewatering machine consists of a frame, a transmission system, a feeding part, a juice extracting part, a hydraulic system, and a shroud, and a level control part. The spiral is divided into three parts: the spiral feeding, the thickening zone, and the pressing spiral. The pressing of the material is realized by pressing the sieve cylinder and the material stopping device, and the extrusion of the material is realized by the blocking door and the backing screen cylinder of the material outlet.
Features:
- Stainless steel wetted parts for abrasive waste and residues.
- Peak values in dry matter content.
- Heavy-duty construction.
- Hydraulic backpressure cone devise
- Two-piece screen design allows for easy cleaning and maintenance
- Can accept widely varying flow rates
- Custom Designed for Every Application
- Easy to install and operate.
Application:
- Pulp and Paper Industries
- Food Processing & Agriculture
- Chemical Industry
- Municiple Biosolid
